Hes 9500 Fire Rated Electric Strike
Regular price
Quantity: In Stock
SKU: 9500
Best 11B722 Padlock Less Core Brushed Brass Finish
$80.00
Best 11B722 Padlock Less Core Brushed Chrome Finish
$58.00
Best 11B782 Padlock Less Core Brushed Brass Finish
$91.00
Best 11B782 Padlock Less Core Brushed Chrome Finish
$69.00
- Description
The Hes 9500 is a surface mounted fire rated electric strike. Designed to work with most rim panic bar devices. Voltage can be chosen in the field, 12 or 24 VDC. Installation requires no cut out. Standard finish US 32D stainless steel.
Specifications
- UL 10C fire-rated, 1-1/2 hr (fail secure only)
- CAN4-S104 (ULC-S104) fire door conformant
- WHI fire door listed
- UL1034 burglary-resistant listed
- ANSI/BHMA 156.31, Grade 1 (#E09371, #E09372)
- NFPA-252 fire door conformant
- ASTM-E152 fire door conformant
- California fire marshall listed
- UBC-7-2-94, Uniform Building Code
- Patented design
Frame application
- Steel
- Wood
Electrical (continuous duty)
- .45 Amps @ 12VDC
- .24 Amps @ 24VDC
Standard Features
- Completely surface mounted
- Stainless steel construction
- Tamper resistant
- Static strength 1,500 lbs.
- Dynamic strength 70 ft-lbs.
- Endurance 500,000 cycles
- Field selectable fail safe/fail secure
- Dual voltage 12 or 24 VDC
- Horizontal adjustment
- Non-handed
- Internally mounted solenoid
- Accommodates up to 3/4" pullman latch
- Five year limited warranty
Optional Features
- LBM - Latchbolt monitor
- LBSM - Latchbolt strike monitor
Accessories
- 9500/9600-108 - Spacer plate
- 154 - MTK Metal Template Kit
- 2001 - Plug-in bridge rectifier
- 2004 - ElectroLynx adapter
- 2005 - SMART Pac II
- 2006P - Plug-in buzzer
- 2009P - Plug-in LED
Finishes
- 630 Satin stainless steel
- 605 Bright brass
- 606 Satin brass
- 612 Satin bronze
- 613 Bronze toned
- 629 Bright stainless steel
